1. 800X480 High resolution image
2. easy installation;
3. More bigger screen 4.0 inches;
4. 160 wide degree angles viewing
5. 24 hours security surveillance
Advantages:
1. Wide view angle:160degree
2.Lowpower consumption:Press the button for about 3000times,
15seconds/time with 3AAAbatteries
3. Clean and big image:2.0Mega Pixel CMOS sensor,4.0inch HD
LCD,hight resolution:800x480
4. Photo snapping with 1G built-in memory,about 100 photos can be
stored.
5.Easy assemble:no wires,no damage on the door,no tools
6.Thickness:only 16mm
7.Good appearance:curve modeing,camera outside the door only 6.5mm
in thickness
8.Time and date can be stored,one month without batteries.
Technical specifications:
| Digital Door Viewer |
| Item: | Gausst DDV |
| Model: | GS8040 |
| Specifications: | Screen size: | 4.0 inch LCD |
| View angle: | 160 degree |
| Sensor: | 2.0 Mega Pixel CMOS |
| Power source: | 3 AAA batteries (good for approx 4000 peep) |
| Response: | 1 second after pressing button |
| Certificate: | CE FCC ROHS |
| Materials: | Brass and stainless steel |
| Fit door thickness: | 30-110mm (1.18"-4.32") |
| Fit barrel hole | 14-28mm |
| Frame Size: | 115(W)x64(H)x16(D)mm |
| Net Weight: | 210g |
dvantages
of the Item: | -- Clear and big image (2.0 mage Pixel CMOS sensor, 4.0 inch HD
LCD,high resolution:800X480) |
| -- Quick response: 1 second after pressing the button |
| -- Less Weight: total 198g with inner box |
| -- Easy operation: just press the button, the image shows. |
| -- DDV will turn off in 15 seconds automatically to save power |
|
|
| | |
| Color: | silver,champange,gold, black, red ….. to be customized |
| |
| Logo: | Customer logo and package design also be available |
| Provided the order quantity is more than 1000 units |
| | |
| Package: | - 1 unit in an individual color box |
| - Color box: 160(W)x115(H)x35(D)mm |
| - 30 sets in an master carton |
| - Carton size: 355 x345x220mm |
| | |
| Notice: | Operating temperature: -15°C~50°C |
| Prevent beats and water mist
|
Packaging & Delivery
Packaging Detail: 1 unit in an individual color box Color box:
122(W)x66(H)x16(D)mm ,30 sets in an master carton
Carton size:355x345x220mm, Gross Weight: 6.8kgs
Delivery Detail: 25 working days after order confirmed
